16 Channel HD-SDI Digital Video Recorder


  • Stand-alone Linux ASIC system
  • 480 FPS at 720p or 240 FPS at 1080p
  • Back-up to CD-RW, DVD, USB drive, or PC via SMS remote software
  • 3 TB SATA HDD comes standard (Holds up to four hard drives internally)
  • Redundant operating system on flash memory and hard drive
  • Embedded remote software file on video clip for PC viewing- no software installation
  • HDMI, HD-SDI, & VGA monitor outputs
  • Search by channel, time, date, motion, event, or new museum search feature
  • Jog-wheel for easy searching
  • Multiple recording rates for schedule, motion, event, time, and day
  • Pentaplex operation
  • Full HD 1920 x 1080 monitor output
  • RAID configurable
  • E-mail notification, pop-up window, log file
  • Panorama search frame-by-frame
  • View live & recorded content with the CEC Connect (iOS & Android*) App.
  • SMS remote software included

SRX-Pro Hybrid 4P1604

The SRX-Pro Compact series is an alternative to the standard rackmount system. Supporting analog and IP cameras, the hybrid SRX-Pro Compact is ideal for transitioning to an IP platform while continuing to utilize traditional analog video.

Key Features

• Compact design
• Recording rates up to 480/400 fps (NTSC/PAL)
• 16 analog + 4 IP cameras
• Upgradable up to 32IP
• Slim DVD-RW
• 16 loop-out video outputs
• 2 sensor inputs and 2 control outputs
• Embedded OS
• CMS Support
• Lockable and Wall mountable case
• Video analytics support, up to 16 video channels
• Removable hard drive case
• Multiplexed or spot outputs

RX-Pro Hybrid 9E3200

Global market adoption of IP and megapixel camera technologies drives the need for new surveillance capabilities offered by the SRX-Pro Hybrid 9E3200. Supporting both analog and IP cameras, SRX-Pro is ideal for systems requiring transition to IP to maximize the cost-savings benefits associated with IP networking. Additional benefits are realized for systems adding new capabilities such as unparalleled image clarity using megapixel cameras.

Key Features

• Accepts 32 analog (Optional 28 analog + 4IP)
• Upgradable to an additional 32IP
• JBOD storage and optional RAID5* configuration
• Analytics support, up to 16 video channels
• VGA and DVI-D ports for local live viewing
• Removable storage 1 to 8 HDD
• 2 sensor inputs and 2 control outputs
• Optional multiplexed or switched spot outputs
• Embedded OS
• CMS Support


The all new Pro Series DVR from Clinton Electronics features full D1 resolution at 30 FPS (frames per second) for every channel. One can now record all 16 channels with audio recording. The option still remains to select fewer frames and/ or lower resolution to give one the choice of recording time in storage. Each channel can be customized for different frame rates for motion, alarm, or schedule.


  • Up to 30fps
  • Full D1 704X480
  • 16 Channel
  • Remote SMS software
